M1.2 Metric Thread Dimensions and Pitch

Below are the key dimensions for M1.2 metric threads: pitch, tap drill and clearance drill according to ISO 724:2023.

M1.2 Coarse (standard)

M1.2 Pitch:  0.25mm
M1.2 Tap Drill:  0.95mm
M1.2 Clearance Drill:  1.4mm
Claim your 10% discount and experience bespoke manufacturing.
CNC Milling.
CNC Turning.
Plastic Injection Moulding.
Custom Aluminium Extrusion.
Turbocharger fan.
Custom Sheet Metal Fabrication.
10% off

Need custom metal and plastic parts?

Get 10% off your first order

No newsletter, no marketing, just a discount code for custom parts.

Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.

M1.2 Metric Thread

M1.2 ISO metric thread profile illustration

Welcome to our M1.2 Metric Thread Page. We've curated a thorough library of data for quick measurements on M1.2 metric threads. This resource contains in-depth metrics for common threads you'll need for your parts, including essential measurements such as thread pitch, tap drill, and clearance drill. It's a comprehensive solution for professionals and enthusiasts looking for precise data.

M1.2 Coarse Pitch Dimensions

Nominal Size
d=D
p
r
d2=D2
d3
D1
h3
H1
Tap Drill
M1.2
1.2
0.25
0.036
1.038
0.893
0.929
0.153
0.135
0.95
All dimensions stated in are mm (millimetre)

M1.2 Fine Pitch Dimensions

| Nominal Size | d=D | p | r | d2=D2 | d3 | D1 | h3 | H1 | Tap Drill | |--------------|-----|-----|-------|-------|-------|-------|-------|-------|-----------| | M1.2x0.2 | 1.2 | 0.2 | 0.029 | 1.07 | 0.955 | 0.983 | 0.123 | 0.108 | 1 |

All dimensions stated in are mm (millimetre)

ISO Metric Thread profile

d=D: Major Diameter
p: Pitch
r: Root Radius
d2=D2: Pitch Diameter
d3: Minor Diameter Male Thread
D1: Minor Diameter Female Thread
h3: Thread Height Male
H1: Thread Height Female

Major Diameter

The Major Diameter is the largest diameter on the thread and is measured from the thread crest to crest (peak of the thread).

Pitch

This is the distance (mm) from one thread to the next, this can be measured from tip to tip or groove to groove. Pitch can also be defined as TPI, which stands for threads per inch.

Minor Diameter

Minor Diameter is the smallest diameter on the thread and is measured from the thread root to root (Bottom of the thread).

Thread Angle

The angle between the thread faces. 60 degrees in the example above.

Right-Hand Thread

The thread will assemble when rotated clockwise. "righty tighty lefty loosely"

Left-Hand Thread

The thread will assemble when rotated counter-clockwise.

Frequently Asked Questions

What is the pitch of an M1.2 thread?

The pitch for an M1.2 thread is 0.25 mm.

What is the tap drill for an M1.2 thread?

The tap drill for an M1.2 thread is 0.95 mm.

What size is a clearance hole for an M1.2 thread?

The clearance drill for an M1.2 thread is 1.4 mm.
