M52 Metric Thread Dimensions and Pitch

Below are the key dimensions for M52 metric threads: pitch, tap drill and clearance drill according to ISO 724:2023.

M52 Coarse (standard)

M52 Pitch:  5mm
M52 Tap Drill:  47mm
M52 Clearance Drill:  57mm
Claim your 10% discount and experience bespoke manufacturing.
CNC Milling.
CNC Turning.
Plastic Injection Moulding.
Custom Aluminium Extrusion.
Turbocharger fan.
Custom Sheet Metal Fabrication.
10% off

Need custom metal and plastic parts?

Get 10% off your first order

No newsletter, no marketing, just a discount code for custom parts.

Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.

M52 Metric Thread

M52 ISO metric thread profile illustration

Explore our M52 Metric Thread Page, your indispensable tool for quick measurements on M52 metric threads. We've curated a wide-ranging library of data for all the standard metric threads you'll implement in your components, focusing on key measurements like thread pitch, tap drill, and clearance drill. It's an all-encompassing resource for professionals and hobbyists in need of accurate and reliable information.

M52 Coarse Pitch Dimensions

Nominal Size
d=D
p
r
d2=D2
d3
D1
h3
H1
Tap Drill
M52
52
5
0.722
48.752
45.866
46.587
3.067
2.706
47
All dimensions stated in are mm (millimetre)

M52 Fine Pitch Dimensions

| Nominal Size | d=D | p | r | d2=D2 | d3 | D1 | h3 | H1 | Tap Drill | |--------------|-----|-----|-------|--------|--------|--------|-------|-------|-----------| | M52x1.5 | 52 | 1.5 | 0.217 | 51.026 | 50.16 | 50.376 | 0.92 | 0.812 | 50.5 | | M52x2.0 | 52 | 2 | 0.289 | 50.701 | 49.546 | 49.835 | 1.227 | 1.083 | 50 | | M52x3.0 | 52 | 3 | 0.433 | 50.051 | 48.319 | 48.752 | 1.84 | 1.624 | 49 | | M52x4.0 | 52 | 4 | 0.577 | 49.402 | 47.093 | 47.67 | 2.454 | 2.165 | 48 |

All dimensions stated in are mm (millimetre)

ISO Metric Thread profile

d=D: Major Diameter
p: Pitch
r: Root Radius
d2=D2: Pitch Diameter
d3: Minor Diameter Male Thread
D1: Minor Diameter Female Thread
h3: Thread Height Male
H1: Thread Height Female

Major Diameter

The Major Diameter is the largest diameter on the thread and is measured from the thread crest to crest (peak of the thread).

Pitch

This is the distance (mm) from one thread to the next, this can be measured from tip to tip or groove to groove. Pitch can also be defined as TPI, which stands for threads per inch.

Minor Diameter

Minor Diameter is the smallest diameter on the thread and is measured from the thread root to root (Bottom of the thread).

Thread Angle

The angle between the thread faces. 60 degrees in the example above.

Right-Hand Thread

The thread will assemble when rotated clockwise. "righty tighty lefty loosely"

Left-Hand Thread

The thread will assemble when rotated counter-clockwise.

Frequently Asked Questions

What is the pitch of an M52 thread?

The pitch for an M52 thread is 5 mm.

What is the tap drill for an M52 thread?

The tap drill for an M52 thread is 47 mm.

What size is a clearance hole for an M52 thread?

The clearance drill for an M52 thread is 57 mm.
