M10 Metric Thread Dimensions and Pitch
Below are the key dimensions for M10 metric threads: pitch, tap drill and clearance drill according to ISO 724:2023.
M10 Coarse (standard) |
|---|
| M10 Pitch: 1.5mm |
| M10 Tap Drill: 8.5mm |
| M10 Clearance Drill: 11mm |
M10 Metric Thread
Explore our M10 Metric Thread Page, your go-to resource for quick assessments of M10 metric threads. We've curated a broad spectrum of data for all standard metric threads you'll need for your parts, highlighting important measurements such as thread pitch, tap drill, and clearance drill. It's a complete solution for engineers, machinists, and hobbyists in need of reliable and precise information.
M10 Coarse pitch dimensions
| Nominal Size | d=D | p | r | d2=D2 | d3 | D1 | h3 | H1 | Tap Drill |
|---|---|---|---|---|---|---|---|---|---|
| M10 | 10 | 1.5 | 0.217 | 9.026 | 8.16 | 8.376 | 0.92 | 0.812 | 8.5 |
M10 fine pitch dimensions
All dimensions stated in are mm (millimetre)
ISO Metric Thread profile
Glossary
Major Diameter
The Major Diameter is the largest diameter on the thread and is measured from the thread crest to crest (peak of the thread).
Pitch
This is the distance (mm) from one thread to the next, this can be measured from tip to tip or groove to groove. Pitch can also be defined as TPI, which stands for threads per inch.
Minor Diameter
Minor Diameter is the smallest diameter on the thread and is measured from the thread root to root (Bottom of the thread).
Thread Angle
The angle between the thread faces. 60 degrees in the example above.
Right-Hand Thread
The thread will assemble when rotated clockwise. "righty tighty lefty loosely"
Left-Hand Thread
The thread will assemble when rotated counter-clockwise.
Frequently asked questions
What is the pitch of an M10 thread?
What is the tap drill for an M10 thread?
What size is a clearance hole for an M10 thread?
